Robot-assisted automatic unbalance correction station

Integration into an automated wheel assembly line. Automatic unbalance correction of complete wheels with adhesive weights at multiple planes. Segmented and continuous adhesive weights made of various materials can be processed. Automatic unwinding of the adhesive weights from the spool.

Produkt Beschreibung

• Cycle timt <= 12 seconds
• Wheel diameter 16" to 24"
• Weight of spool approx. 140 kg
• Weight of complete approx. 50 kg
• Automatic, manual and bypass mode
• Robot tool (EOAT) optimized for different types of glue weights
• Application force adjustable (standard value up to 100N)
• Application force display with adjustable limits
• The system is network-capable and has an external data storage
• Automatic force sensor verification function (force validation)
• Processing of different colored adhesive weights possible (manual changeover)Processing of different colored adhesive weights possible (manual changeover)
• Automatic change of adhesive weight color optional, as well as processing of several different adhesive weight colors and types in parallelAutomatic change of adhesive weight color optional, as well as processing of several different adhesive weight colors and types in parallel
